Features
3 bands of dynamic compression with selectable crossovers
- Built-in RDS/RBDS; compatible with all automation
- Built-in Stereo Generator
- Analog, AES-digital, streaming in; MPX/streaming out
- Accepts streaming input for STL´s from IP Encoders on SHOUTcast & ICEcast
- Full function ‘responsive’ Web interface works on desktop and mobile devices
- Gated and ‘windowed’ gain-riding AGC.
- 4 sections of parametric EQ plus an effective ‘Bass Punch’ feature
- GPIOs, Web/email/SNMP for controls and alarms
- Complies with North American and European standards
Specifications
Frequency Response
20Hz-15kHz, ±0.25dB (with an appropriate de-emphasis network)
Distortion
0.02% THD in PROOF mode
Signal-to-Noise
- Analog In: >82dB
- AES Digital In: >90dB (with an appropriate de-emphasis network)
Pre-Emphasis
75μs or 50μs menu-selectable
Program Line Inputs
- Analog: active-balanced (XLR) accepts line levels between –15dBu and +15dBu; +24dBu clipping
- AES Digital: (XLR) accepts line levels between 0dBFS and –30dBFS at sampling rates between 32kHz and 96kHz
- IP Streaming: accepts Icecast/SHOUTcast MP3, Ogg and AAC streams
Composite/MPX Output
75Ω (BNC); adjustable between 1V p-p and 6V p-p 6% – 12% stereo pilot injection; 3% – 8% RDS/RBDS subcarrier injection
Program Signal Latency (Delay)
Approx. 3.75ms
Network Port
TCP/IP network connection (RJ45) for remote setup / operation and in/out audio streaming; full support for SNMP control
GPIO Ports
3 GPI, 3 GPO with assignable functions and logic polarity
Headphone Jack
Front-panel (TRS) 3.5mm
Internal Test Tone Generator
20Hz-20kHz; variable frequency and amplitude
Alarms
Local (GPIO) closures, browser interface, SNMP and SMS/email alarms for analog, digital and stream audio loss; maintains daily, weekly, monthly logs.
Scheduler
- Dayparting is simplified with an onboard real-time clock and preset-selection programming.
- AGC: ±15dB capture range; gated with dual-rate ‘windowed’ operation
- Leveling: variable ‘syllabic’ 2:1 compression
- EQ: 4-sections of parametric equalization
- Bass ‘Punch’: variable bass enhancement
- Compression: 3-bands with selectable crossovers, variable master and individual band drive controls, plus r.m.s./peak ‘density’ adjustment
- Final Peak Control: no-clip feed-forward wideband limiting and independent FM pre-emphasis protection limiting
- Composite Clipping: 0dB – 3dB adjustable MPX clipping depth (exclusive of stereo pilot and RDS/ RBDS subcarrier)
RDS/RBDS
Static & dynamic support for artist and song title display in PS and RT fields
Power Requirement
12VDC at 400mA (2.1mm x 5.5mm coaxial); inline switchmode power supply included
Mounting Options
An optional rack adapter mounts one or two NOVIA or other Inovonics half-rack units in a standard 19-inch, 1U rack space
Size and Weight
1.6”H x 8”W x 6”D; 5 lbs shipping weight
